Electricity single-phase smart meter Pulsar with DLMS

detail__img

Price on request

Скидка предоставляется на оптовые партии при указании адреса объекта

Купить оптом

Description

They are designed for measuring and recording in multi-tariff mode active (in one or two directions) and reactive electrical energy.

Interfaces

  • Optical port
  • RS-485
  • RS-485, NB-IoT+2G
  • LoRa
  • NB-IoT+2G
  • NB-IoT
  • 2G
  • PLC+RF
  • RF

Interfaces can be combined

Available according to IEC 62052.

  • Active and reactive energy metering
  • Powerful built-in microcontroller
  • Relay with blocking capability magnetic field immunity
  • Non-detachable body
  • Wall mounted or DIN rail
  • Data history
  • Bidirectional measurement of active power
Accuracy class when measuring active IEC 62053-21/ reactive energy according to IEC 62053-23 Class 1/ 1 or 2
Rated voltage Unom, V 230
Base/maximum current Ib/Imax, A 5/60; 5/100; 10/100
Network frequency, Hz 50±7,5
Established operating voltage range, V (0,9…1,1) Unom
Extended operating voltage range, V (0,8…1,15) Unom
Network voltage measurement range, V 175…310
Basic voltage measurement error, % 0,5
Main current measurement error, % 0,5
Basic error of network frequency measurement, Hz 0,05
Limit of the main absolute error of the clock under normal conditions, s/day ±0,5
Data safety during power interruptions, years 32
Operating temperature range, °C -40...+70
Storage temperature range, °C -40...+70
Archives with variable integration time/hours/days/months 100 days (at 30 minute intervals) /4320/180/42
Meter weight, kg, no more 0,5
Calibration interval, years 16
Lithium battery life, years 16
Average meter service life, years 35
Overall dimensions (height х length х width), mm 117х114х64
